Blade
Miniaturní průmyslové Box PC Procesor Intel® Bay Trail-D J1900 CPU
Základní informace
| Dostupné desky pro toto šasi: | ||||||||||||||||||
|
| Volitelné vlastnosti | ||
| Wi-Fi | GPS | Wide range DC-IN |
Specifikace
| MODEL | BLADE + 2I385S | |
| System Dimension(WxDxH) | 150W x 80.8D x 18H mm | |
| Weight(Incl.M/B) | 0.26kg | |
| CPU | Intel Bay Trail-D J1900 2.0 GHz (Quad Core) | |
| Chipset | ||
| Memory | Type / Capacity | J1900 DDR3L 1333MT/s |
| On board memory | 2GB | |
| SSD storage | mSATA | YES |
| On Board SSD | N/A | |
| HDD Space | mSATA | |
| VGA | N/A | |
| DVI / HDMI | 1 x HDMI, 1 x Mini HDMI | |
| USB | 3 (USB 3.0 x1 + USB 2.0 x 1 + Micro USB x 1) | |
| COM | N/A | |
| Mini-PCIe | 2 | |
| SIM Card Holder | N/A | |
| GPIO | N/A | |
| Ethernet | 2 x GbE | |
| Mic-in / Line-out | Line-out / Mic-in | |
| Power Input | DC IN +12V ; +9~36V (Optional) | |
| Expansion | 3G / 4G, GPS, Bluetooth, WI-FI | |
| Optional MB | N/A | |
| Operating Temp. | 0ºC~50ºC for mSATA | |
| Operating Humidity | 5~95% @ 60ºC, non-condensing | |
Popis
| MODEL | BLADE System |
| Dimension | 18H x 150W x 80.8D mm |
| Material | Aluminum |
| Color | Blue & Silver |
| Weight | 0.26 Kg (Incl. M/B) |
| Storage Space | mSATA |
| Optional Accessory | Wall Mount kit |
Fotogalerie
Zobrazit všechny fotky
