10.1" SHARK

10.1" SHARK Bezel-free Fanless Panel PC

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073 pchalupa@nowatron.cz

Dostupné základní desky:

MODEL		10.1" + 2I268C
Dimension (mm)		250W x 40H x 168D mm
Weight		2.3 Kg
Hard drive		2.5" HDD
LCD brand		CPT
LCD size		10.1 inch, 16:9
Max Resolution		1280 x 800
Luminance (cd/m2)		500
Contrast Ratio		500:1
Viewing Angle (H-V)		140(H)-120(V)
Backlight		LED
Touch Screen		Resistive touch screen
MB		2I268C-DVI
CPU		Intel Cedarview-M N2600/N2800 1.6/1.86 GHz
Chipset		Intel Cedarview-M + NM 10
Memory	Type / Capacity	DDR3 800 MT/s for N2600, Max up to 2GB DDR3 1066 MT/s for N2800, Max up to 4GB
	SO-DIMM	N/A
	On board memory	2GB
SSD Storage	CF (CFast)	N/A
	mSATA	Yes (Half Size)
	On Board SSD	Optional
VGA		YES
DVI / HDMI		DVI
USB		Built-in 2 x USB, expand up to 5 x USB
COM		Built-in 1 x COM, expand up to 2 x COM
MiniPCIe		2
SIM Card Holder		Optional
GPIO		4DI / 4DO (Optional)
Ethernet		Realtek GbE x 1
Audio		Line-out
Power Input		DC IN +12V
Battery		option (3500~10500mAh)
Mounting		VESA 75
Panel frame water proof		IP65
Optional MB		2I385CW
Expansion		GPS, 3G/4G, Bluetooth, WI-FI, I/O
Operating Temp.		-20°C~60°C for mSATA
Operating Humidity		5~90% @ 39°C, non-condensing
