EverGreen SATA Slim
With L2 wear leveling architecture, the EverGreen SATA Slim has significantly improved the SSD random data transfer rate and lifespan for data file sizes equal to or smaller than 128KB, in particular. Compliant with JEDEC MO-297 and Serial ATA (SATA) sta
PRODUKT JIŽ NENÍ URČEN K PRODEJI
Základní informace
Features:
•High IOPS
•S.M.A.R.T / iSMART disk health monitoring tool
•Excellent data transfer speed
•MLC-based flash with L2 architecture
•Lifespan 10 times longer than an MLC solution
Benefits:
The Innodisk EverGreen SATA Slim provides manufacturers with a cost-effective MLC flash replacement for hard disk drives (HDDs).
•Delivers longer life and better performance than current MLC flash IC based SSD solutions
•Improves SSD random data transfer rate and lifespan, particularly for data file sizes equal to or smaller than 128 KB
•Reduces operation system boot time
•Consumes less power than an HDD
Specifikace
| Model Name | EverGreen SATA Slim |
| Interface | SATA II 3.0Gb/s |
| Type | Standard |
| Flash Type | MLC |
| Connector | 7pin+15pin |
| Capacity | 32GB~128GB |
| Max. Channels | 8 |
| Sequential R/W (MB/sec, max.) | 220/150 |
| Max. Power consumption | 2.5W (5V x 500mA) |
| Thermal Sensor | N |
| External DRAM Buffer | Y |
| H/W Write Protect | N |
| ATA Security | Y |
| S.M.A.R.T. | Y |
| Conformal Coating | N |
| Dimension (WxLxH/mm) | 54.0 x 39.8 x 6.8 |
| Vibration | 20G@7~2000Hz |
| Shock | 1500G@0.5ms |
| MTBF | >3 million hours |
| Storage Temperature | -55°C ~ +95°C |
| Operation Temperature | Standard Grade: 0°C ~ +70°C; |
| Extended Grade: -20°C ~ +85°C |
