AV1000

Dual NVIDIA RTX6000 Liquid Cooled GPU Server with Intel Xeon Scalable (ICE LAKE) CPU

Petr Chalupa

Petr Chalupa

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073

Základní informace

  • Thermal Dissipation Coefficient : 10KW
  • Liquid Cooled Platform : Gun Drilled -10 x 500 x 10mm Pass (⌀ x L x H)
  • CPU: 3rd Gen. Intel Xeon Scalable ( ICE LAKE ) ® Platinum 8380 (40 x cores, 2.3 GHz, 270W)
  • GPU: 2 x NVIDIA RTX 6000 (24 GB GDDR6, 4,608 CUDA Cores)
  • 8 x DDR4-3200MHz up to 2TB
  • 18V~36V DC-IN DC-DC 1000W
  • Storage(1): 2 x NVMe SSD (1 x PCIe Gen 4.0 x4, 1 x PCIe Gen 4.0 x8)        up to 48TB
  • Storage(2): 4 x SATA 6.0 SSD up to 16TB
  • Dimension: 450 x 500 x 88 mm (WxDxH)

The global transformation is rapidly scaling the demands for flexible computer, networking, and storage. Future workloads will necessitate infrastructures that can seamlessly scale to support immediate responsiveness and widely diverse performance requirements. The exponential growth of data generation and consumption, the rapid expansion of cloud-scale computing and 5G networks, and the convergence of high-performance computing (HPC) and artificial intelligence (AI) into new usages requires that today’s data centers and networks evolve now— or be left behind in a highly competitive environment.

7Starlake's AV1000 AI Inference Rugged Server which are featuring 3rd Gen. Intel Dual Xeon Ice Lake Scalable Processors (40 Cores, 2.3 GHz, 270W) with 2 x NVIDIA QUADRO RTX6000, 8 x DDR4-3200MHz  2TB memory and 2 x NVMe SSD up to 48TB, to provide the seamless performance foundation for the data centric era from the multi-cloud to intelligent edge, and back. The Intel Xeon Scalable platform provides the foundation for an evolutionary leap forward in data center agility and scalability. Disruptive by design, this innovative processor sets a new level of platform convergence and capabilities across compute, storage, memory, network, and security.

AV1000 enables a new level of consistent, pervasive, and breakthrough performance in new AI inference to implement machine learning and deep learning. In addition to NVIDIA QUADRO RTX6000, AV1000 provides one M.2 NVMe slot for fast storage access. Combining stunning inference performance, powerful CPU and expansion capability, it is the perfect ruggedized platform for versatile edge AI applications.

With innovative liquid cooled design, AV1000 is built in most advanced " Gun Drilled ", which with 10 pipes (each pipe 5mm x 5mm x \pi  x 500mm) to dissipate max 10KW heat.

Specifikace

CPU

3rd Gen. Intel Xeon Scalable ( ICE LAKE ) ® Platinum 8380 (40 x cores, 2.3 GHz, 270W)

Memory type

DDR4-3200MHz up to 2TB

GPU

2 x NVIDIA RTX 6000 (24 GB GDDR6, 4,608 CUDA Cores)

Storage(1)

2 x NVMe SSD (1 x PCIe Gen 4.0 x4, 1 x PCIe Gen 4.0 x8) up to 48TB

Storage(2)

4 x SATA 6.0 SSD up to 16TB

Ethernet

2 x 10G Base-T

VGA

1 (M12)

Ethernet

2 x 10GbE (M12)

USB

2 x USB 3.0 (M20)

IPMI

1 x IPMI 2.0

Power

18V~36V DC-IN DC-DC 1000W

Dimension

450 x 500 x 88 mm (W x D x H)

Fotogalerie

Ke stažení
